Mobile On Rail Transfer Cart , Material Transfer Trolley KPJ - 20T Model

  • Mobile On Rail Transfer Cart , Material Transfer Trolley KPJ - 20T Model
  • Mobile On Rail Transfer Cart , Material Transfer Trolley KPJ - 20T Model
  • Mobile On Rail Transfer Cart , Material Transfer Trolley KPJ - 20T Model
  • Mobile On Rail Transfer Cart , Material Transfer Trolley KPJ - 20T Model
  • Mobile On Rail Transfer Cart , Material Transfer Trolley KPJ - 20T Model
Place of Origin Xinxiang
Brand Name BEFANBY
Certification CE,SGS,ISO9001
Model Number KPJ-20T
Price Negotiation
Packaging Details Electrical parts will add shields. As required by the customer, we can add a fixed packing.
Delivery Time 50-60 days as usual delivery,40-50days for urgent delivery
Payment Terms 30% deposit by T/T in advance, 70%balance by T/T before dispatch
Supply Ability 600 sets one year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Power Supply Mode Mobile Cable Power Rated Load 20t
Material Steel Car Size Customized
Load Capacity Up To 300ton Electrical Parts Simens,Schneider, Nord
Safety Device Warning Lamp, Siren, Bumper Exported Countries Holland, Syria, Germany,
High Light

motorized industrial carts

,

motorized material handling equipment
Leave a Message
Product Description

KPJ-20T Cable reel powered motor rail trolley for industry product transport



Product information

The railway trolleys is powered by cable reels at the bottom of the carts. One end of AC 380V cable is connected with the power source and the other end is linked to the motor. The cable is wound around cable reel. When the carts run, the cable reels let out or collect the cable.

Mobile On Rail Transfer Cart , Material Transfer Trolley KPJ - 20T Model 0



Components

Cart frame, cart wheels, AC motor, speed reducer, cable drum, cable arranger, electrical control box,hand-held pendant, remote controller, alarm light

Mobile On Rail Transfer Cart , Material Transfer Trolley KPJ - 20T Model 1



Function



a. High-temperature and anti-explosion condition

b. Used to transfer materials from one workshop to another

c. It can be used in the high-temperature environment and other worse condition with the strong bearing ability.

d. The turning rail transfer carts can run on the rails ‘S’, arc-shaped, direct running and so on.

Mobile On Rail Transfer Cart , Material Transfer Trolley KPJ - 20T Model 2



Merits



Simple structure

Can be used frequently

No restriction of the running time

No strict requirement for the railway construction

Mobile On Rail Transfer Cart , Material Transfer Trolley KPJ - 20T Model 3



Parameter list

model KPJ-2T KPJ-10T KPJ-20T KPJ-30T KPJ-50T KPJ-63T KPJ-150T
Rated load (T) 2 10 20 30 50 63 150
Table size length(L) 2000 3600 4000 4500 5500 5600 10000
Width(W) 1500 2000 2200 2200 2500 2500 3000
Height(H) 450 500 550 600 650 700 1200
Wheel Base (mm) 1200 2600 2800 3200 4200 4300 7000
Rail Inner Gauge (mm) 1200 1435 1435 1435 1435 1435 2000
Wheel Diameter(mm) Φ270 Φ300 Φ350 Φ400 Φ500 Φ600 Φ600
Wheel Quantity 4 4 4 4 4 4 8
Ground Clearance (mm) 50 50 50 50 50 75 75
Running speed (min) 0-25 0-25 0-20 0-20 0-20 0-20 0-18
Motor Power (Kw) 1 1.6 2.2 3.5 5 6.3 15
Max Wheel Load (KN) 14.4 42.6 77.7 110.4 174 221.4 265.2
Reference Weight (t) 2.8 4.2 5.9 6.8 8 10.8 26.8
Recommended Rail Model P15 P18 P24 P38 P43 P50 QU100





About us



Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd is a collection of research, design, manufacture, installation and after-sales service of electric handling bogie ,transfer carts as one of the professional manufacturing company, which has a modernized management team and excellent staff.And our prodcuts gets CE, SASO,SGS,ISO certificate and other 8 national patent, and our products have been exported to more than 40 countries and regions.



Mobile On Rail Transfer Cart , Material Transfer Trolley KPJ - 20T Model 4




Payment terms L/C, T/T
Packaging According customer's demand
Shipment port Qingdao, Tianjin, Shanghai
Minimum order 1 SET
Certificates CE, SGS, ISO



If you have any queations about the rail trolleys, pls contact me.
