Flatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar Power

China Flatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar Power supplier
Flatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar Power supplier Flatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar Power supplier Flatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar Power supplier Flatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar Power supplier Flatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar Power supplier

Large Image :  Flatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar Power

Product Details:

Place of Origin: Xinxiang
Brand Name: BEFANBY
Certification: CE,SGS,ISO9001
Model Number: KPC-20T

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Electrical parts will add shields. As required by the customer, we can add a fixed packing.
Delivery Time: 50-60 days as usual delivery,40-50days for urgent delivery
Payment Terms: 30% deposit by T/T in advance, 70%balance by T/T before dispatch
Supply Ability: 600 sets one year
Minimum Order Quantity: 1 SET
Contact Now
Detailed Product Description
Power Supply Mode: Busbar Power Application: Heavy Industry
Car Size: Can Be Customised Load Capacity: Up To 300 Ton
Electrical Parts: Siemens, Schneider, Nord Saftey Devices: Warning Lamp, Siren, Bumper
Exported Countries: South Africa, Australia, Syria Product Name: Flatbed Large Workpiece Railroad Cart For Building Construction
Wheel Diameter(mm): 400 Rail Gauge(mm): 1435
Wheel Quantity: 4 Pcs Contact: Marketing@bfbhandling.com
Warranty: 12 Months Port: Qingdao, Tianjin, Shanghai

Flatbed large workpiece railroad cart for building construction

Working of railroad cart


Railroad cart is very popular with the customers for assembly line. This kind of railway cart is power by busbar(electric sliding line). It gets power from sliding line during the cart running. The electric control system of the cart realize it start, stop, go forward and backward. It is suitable to applied in production line or assembly line, to transfer heavy material or parts, the distance is better to less than 50m.

Flatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar Power

Advantages of railroad cart
  • Box girder structure, not easy to deform
  • simple structure, low cost
  • no strict requires on rails
  • can be applied high using frequency condition
  • can be used in high-temperature environment
  • can be used in explosion-proof environment
  • the first choice for production line
Production of railway cart


railway cart


Technical parameters of railroad cart

Model
KPC-2T KPC-10T KPC-20T KPC-30T KPC-50T KPC-63T KPC-150T
Rated load (T) 2 10 20 30 50 63 150
Table size length(L) 2000 3600 4000 4500 5500 5600 10000
Width(W) 1500 2000 2200 2200 2500 2500 3000
Height(H) 450 500 550 600 650 700 1200
Wheel Base (mm) 1200 2600 2800 3200 4200 4300 7000
Rail Inner Gauge (mm) 1200 1435 1435 1435 1435 1435 2000
Wheel Diameter(mm) Φ270 Φ300 Φ350 Φ400 Φ500 Φ600 Φ600
Wheel Quantity 4 4 4 4 4 4 8
Ground Clearance (mm) 50 50 50 50 50 75 75
Running speed (min) 0-25 0-25 0-20 0-20 0-20 0-20 0-18
Motor Power (Kw) 1 1.6 2.2 3.5 5 6.3 15
Battery Capacity(Ah) 180 160 180 250 330 400 600
Battery Voltage(V) 24 48 48 48 48 48 72
Running Time When Full Load 4.32 4.8 4 3.5 3.3 3 2.9
Running Distance for one Charge(Km) 6.5 7.2 4.8 4.2 4 3.6 3.2
Max Wheel Load (KN) 14.4 42.6 77.7 110.4 174 221.4 265.2
Reference Weight (t) 2.8 4.2 5.9 6.8 8 10.8 26.8
Recommended Rail Model P15 P18 P24 P38 P43 P50 QU100

Application of railroad cart

Flatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar Power Flatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar PowerFlatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar Power Flatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar Power

Delivery of railroad cart


railway cartFlatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar Power
Flatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar PowerFlatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar Power


Customer visit in our factory


railway cart railway cart


Related products in our factory


Flatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar PowerFlatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar PowerFlatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar PowerFlatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar Power


BEFANBY company


Flatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar Power


Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd is a professional and experienced manufacturer,exporter of material transfer car in China which have more than 16 years' experience, meanwhile we also design material handling solution according to client's demand





Parts of BEFANBY Certificates


Flatbed Large Workpiece Coil Transfer Cart For Building Construction Busbar Power


BEFANBY advantages
  • The load bearing safety factor of the trolley is no less than 120%.
  • Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.
  • 16 hours engineering service and 24 hours internet service for our customers.
  • During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.
  • Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.
