Dc Motor Mobile Hydraulic Lifting Transfer Cart Remote Control Scissor
Place of Origin | Xinxiang |
---|---|
Brand Name | BEFANBY |
Certification | CE,SGS,ISO9001 |
Model Number | KPX |
Minimum Order Quantity | 1 set |
Price | Negotiation |
Packaging Details | Electrical parts will add shields. As required by the customer, we can add a fixed packing. |
Delivery Time | 40-50 days as usual delivery,30-40days for urgent delivery |
Payment Terms | L/C, T/T |
Supply Ability | 100 sets per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xCapacity(t) | 1-1500 Tons | Color | Red, Yellow, Blue |
---|---|---|---|
Operation Type | Hand Pendant+ Remote Control | Warranty | 2 Years |
Running Speed | 0-20m/min | Motor | Dc Motor |
Power Source | Battery Powered, Customized Power Source | OEM | Accept |
High Light | Mobile Scissor Lift Transfer Cart,Dc Motor Hydraulic Lifting Transfer Cart,Remote Control Scissor Lift Transfer Cart |
Mobile Remote Control Scissor Lift Transfer Cart
The scissor lift transfer cart is an advanced and mature electric flatbed cart transport vehicle for unlimited distance construction in enterprises, which can effectively solve the transportation between workshops/factorys/production lines. it is mainly composed of four-wheel steering system, storage battery, dc motor, high-voltage bearing, lifting device, cart body frame, driving control device, electrical components, etc. the whole frame is easy to split and transport. scissore lift transfer cart has the characteristics of smooth driving, simple lifting control, large bearing capacity and long service life. it is widely used in equipment manufacturing, mining, machinery, heavy industry and textile light industry.
Model | KPX-2T | KPX-10T | KPX-20T | KPX-30T | KPX-50T | KPX-63T | KPX-150T | |
Rated load (T) | 2 | 10 | 20 | 30 | 50 | 63 | 150 | |
Table size | length(L) | 2000 | 3600 | 4000 | 4500 | 5500 | 5600 | 10000 |
Width(W) | 1500 | 2000 | 2200 | 2200 | 2500 | 2500 | 3000 | |
Height(H) | 450 | 500 | 550 | 600 | 650 | 700 | 1200 | |
Wheel Base (mm) | 1200 | 2600 | 2800 | 3200 | 4200 | 4300 | 7000 | |
Rail Inner Gauge (mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 2000 | |
Wheel Diameter(mm) | Φ270 | Φ300 | Φ350 | Φ400 | Φ500 | Φ600 | Φ600 | |
Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
Ground Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 75 | 75 | |
Running speed (min) | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 | |
Motor Power (Kw) | 1 | 1.6 | 2.2 | 3.5 | 5 | 6.3 | 15 | |
Battery Capacity(Ah) | 180 | 160 | 180 | 250 | 330 | 400 | 600 | |
Battery Voltage(V) | 24 | 48 | 48 | 48 | 48 | 48 | 72 | |
Running Time When Full Load | 4.32 | 4.8 | 4 | 3.5 | 3.3 | 3 | 2.9 | |
Running Distance for one Charge(Km) | 6.5 | 7.2 | 4.8 | 4.2 | 4 | 3.6 | 3.2 | |
Max Wheel Load (KN) | 14.4 | 42.6 | 77.7 | 110.4 | 174 | 221.4 | 265.2 | |
Reference Weight (t) | 2.8 | 4.2 | 5.9 | 6.8 | 8 | 10.8 | 26.8 | |
Recommended Rail Model | P15 | P18 | P24 | P38 | P43 | P50 | QU100 |
- Our commitment: The load bearing safety factor of the trolley is no less than 120%.
- Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.
- 16 hours engineering service and 24 hours internet service for our customers.
- During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.
- Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.
