Workshop Transfer Electric Lifting Moving Cart Trolley
Place of Origin | Henan,China |
---|---|
Brand Name | BEFANBY |
Certification | CE,SGS,ISO9001 |
Model Number | KPX |
Minimum Order Quantity | 1 set/sets |
Price | Negotiation |
Packaging Details | The battery power rail cart will be packed by the tarp, the parts will be shipped in the high quality wooden case. |
Delivery Time | 40-50 days as usual delivery,30-40days for urgent delivery |
Payment Terms | L/C, T/T, Western Union |
Supply Ability | 1500 set/sets, per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xColor | Customized | Function | Lifting System Customization |
---|---|---|---|
Application | Workshop, Warehouse, Production Line | Running Speed | 0-20m/min |
Load Capacity | 1-1500 Ton Payload | Power Supply | Battery Powered |
High Light | Moving Battery Transfer Cart,Workshop Transfer Electric Lifting Trolley,Electric Cart Trolley 20m/min |
Workshop Transfer Electric Lifting Moving Cart Trolley
In daily life, the shadow of electric lifting moving cart trolley is not uncommon. It mainly appears in docks, stations, airports, high-speed rail stations, logistics parks, warehouses, factories, industrial parks and other places. Its function is short-distance point-to-point cargo handling. The frequency is very high. For different site environments, companies will customize different types of flatbed trucks with electric lifting moving cart manufacturers, such as size, power, cruising range and other functions. Therefore, the appearance of the electric flatbed vehicles we have seen is different.
It is actually very simple to realize the lifting function of the electric flatbed body, as long as a hydraulic pump is installed under the body. Note that at least four hydraulic pumps must be installed to allow the lifting balance to rise and fall, and to make the lifting power more sufficient. The power of the electric flatbed is mainly determined by the power of the motor, and the cruising range is determined by the battery. Therefore, in terms of customization selection, it is necessary to explain the requirements with the electric flatbed truck manufacturer, such as: how much load, how to use electric vehicles, battery life, length, width and height of the board, etc., to customize an electric flatbed truck suitable for the company's own use.
Technique Parameter of transfer cart
Model | KPX-10t | KPX-16t | KPX-25t | KPX-30t | KPX-40t | KPX-50t | KPX-63t | KPX-80t | KPX-100t | KPX-150t | |
Rated Load | 10 | 16 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
Table size | Length(L) | 3600 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
Width(W) | 2000 | 2000 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 | |
Height(H) | 500 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 | |
Wheel Base | 2600 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
Rail Inner Gauage | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
Wheel Diameter | 300 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 | |
Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
Ground Clearance | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
Running Speed | 25 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 18 | |
Motor Power | 2 | 2.2 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 | 15 | |
Battery Capacity | 160 | 180 | 250 | 250 | 300 | 330 | 400 | 400 | 440 | 600 | |
Battery Voltage | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 | |
Max Wheel Load | 42.6 | 64.5 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
Reference Weight | 4.2 | 5.5 | 6.5 | 6.8 | 7.6 | 8 | 10.8 | 12.8 | 14.6 | 26.8 |
All can be customized as per customers’ requirement.And BEFANBY business is meeting your business need, hope our professional team can help you well with rich experience.
