Intelligence Autonomous 15 Tons AGV Robots
| Place of Origin | Henan,China |
|---|---|
| Brand Name | BEFANBY |
| Certification | CE,SGS,ISO9001 |
| Model Number | AGV battery |
| Minimum Order Quantity | 1 set/sets |
| Price | Negotiation |
| Packaging Details | The AGV robots will be packed by the tarp, the parts will be shipped in the high quality wooden case. |
| Delivery Time | 40-50 days as usual delivery,30-40days for urgent delivery |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 1500 set/sets, per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Power | Battery Powered | Warranty | 24 Months |
|---|---|---|---|
| Load Capacity | 1-1500 Ton | Application | Workshop, Production Line,factory |
| Running Ways | On Rails | Power Supply | Lithium Battery Power, Optional Power Supply |
| Characteristic | Automatic | ||
| High Light | Intelligence Autonomous AGV Robots,15 Tons AGV Robots,Rail AGV Automatic Guided Vehicle |
||
Product Description
Intelligence Autonomous 15 Tons AGV Robots
The AGV robots is an automated material handling device. The intelligent electric flat cart is equipped with an automated program and can move itself under the guidance of a navigation device. There is no limit on the running path of AGVs. The technicians set the running route in advance, so that AGVs can be operated between different working points.
The automatic guided transfer can also be paired with the control panel, where a range of operations can be performed. There are many navigation modes of AGV, such as laser navigation, magnetic navigation, qr code navigation , wireless navigation, etc.Moreover, our AGV is also equipped with a safety system, which can guarantee the stability and safety of mobile robot in work.
AGV, as an automated management vehicle, can effectively improve production efficiency and transportation flexibility.
Application
Parts Details
Product Parameter
| Model | AGV-2T | AGV-5T | AGV-10T | AGV-20T | AGV-30T | AGV-40T | AGV-50T | |
| Rated load(t) | 2 | 5 | 10 | 20 | 30 | 40 | 50 | |
| Table Size | Length(mm) | 2000 | 2500 | 3000 | 3500 | 4000 | 5000 | 5500 |
| Widthmm) | 1500 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | |
| Heigth(mm) | 450 | 550 | 600 | 800 | 1000 | 1200 | 1300 | |
| Wheel Base(mm) | 1080 | 1650 | 1650 | 1650 | 1650 | 2000 | 2000 | |
| Wheel Dia.(mm) | Φ200 | Φ280 | Φ350 | Φ410 | Φ500 | Φ500 | Φ550 | |
| Battery Voltage(V) | 48 | 48 | 48 | 72 | 72 | 72 | 72 | |
| Weel Quantity(pcs) | 4 | 4 | 4 | 4 | 4 | 4 | 4 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | |
| Max Wheel load(KN) | 14.4 | 25.8 | 42.6 | 77.7 | 110.4 | 142.8 | 174 | |
| Reference Wight(t) | 2.3 | 3.6 | 4.2 | 5.9 | 6.8 | 7.6 | 8 | |
Customized manufacture all kinds of transfer cart
