360 Degree AGV Trolley 380 Mm Mecanum Wheel 15 Inch
| Place of Origin | Henan,China |
|---|---|
| Brand Name | BEFANBY |
| Certification | ISO,CE |
| Model Number | Mecanum Wheel |
| Minimum Order Quantity | 1 Piece |
| Price | Negotiation |
| Packaging Details | Mecanum wheel is put into the high quality wooden case. |
| Delivery Time | 30-40 days as usual delivery,20-30days for urgent delivery |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 100 piece/pieces, per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | 360 Degree AGV Trolley 380 Mm Mecanum Wheel 15 Inch | Specifications | As Your Request |
|---|---|---|---|
| Size | Customized | Diameter | Customized |
| Wheel Material | Pu | Quality Control | Professional Inspection |
| High Light | 360 Degree Industrial Mecanum Wheels,Mecanum Wheel 15 Inch,AGV Trolley Mecanum Wheel |
||
Product Description
360 Degree AGV Trolley 380 Mm Mecanum Wheel 15 Inch
Product Description of Mecanum Wheel
The mecanum wheel is a wheel-based mechanical device that can provide a full range of mobility for robots and other devices and achieve flexible steering in small Spaces. As one of the innovations in robotics, mecanum wheel has been widely used in various fields.
The mecanum wheel usually consists of three or more rollers that are perpendicular to the wheel and can rotate independently in different directions to enable complex movement and steering.
One of the main advantages of the mecanum wheel is its ability to move in all directions. Whereas traditional wheels typically move forward or backward in only one direction, mecanum wheels can move in any direction, including forward, backward, left, right, and diagonal. Such characteristics make it possible for robots to accurately navigate and position themselves in small Spaces.
In addition to all-round mobility, the mecanum wheel enables smooth steering operation. Since the rollers of the mecanum wheel can rotate independently, the robot can bypass obstacles with a very small radius when turning. This capability is important for close-space applications such as indoor robots, automated production lines, and medical devices, which need to perform tasks in confined Spaces and need to avoid collisions and interference.
The application scope of mecanum rounds is very broad, covering many different industries and fields. In industrial automation, mecanum wheels can be used for autonomous navigation AGV (automated guided vehicles), robotic handling, and assembly lines, among others. In the medical field, the flexible steering capability of mecanum wheels can be used in surgical robots, medical instruments, and rehabilitation devices, among others. In addition, mecanum wheels are also widely used in logistics, warehousing, cleaning services, aerospace and other fields.
In summary, the mecanum wheel, as a mechanical device that moves in all directions, plays an important role in robotics and automation. Its innovative design enables the robot to flexibly turn in tight Spaces, thus improving the efficiency and accuracy of task execution. With the continuous progress of science and technology and the continuous expansion of applications, mecanum wheel will continue to play its unique advantages in all walks of life, bringing more convenience and benefits to people's life and work.
Product Details Of Mecanum Wheel
Product Parameter Of Mecanum Wheel
| Model | M15-150 | M20-500 | M25-1000 | M31-2500 | M50-4000 |
| Measured diameter(mm) | 151(6”) | 203(8”) | 314(12”) | 406(16") | 508(20”) |
| Width(mm) | 75 | 105 | 158 | 209 | 255 |
| Pour round number(PC) | 8 | 8 | 8 | 8 | 8 |
| Bearing type | Sliding bearing | Needle bearing | |||
| Roller material | Polyurethane (PU) | ||||
| Wheel hub material | 45 # steel | Aviation aluminum 7075 | |||
| Roller core material | 45 # steel | Aviation aluminum 7075 | |||
| Wheel hub surface treatment | Electro nickelling | Surface anodizing | |||
| Type of connection | Shaft cover + keyway | Flange | |||
| Dead weight(kg) | 4.15 | 13.16 | 45 | 45.5 | 87.5 |
| Single wheel load(kg) | 150 | 500 | 1000 | 2500 | 4000 |
| Four wheel load(kg) | 500 | 1500 | 3500 | 8000 | 130000 |
| Note: the above parameters are for reference only, according to the actual signed technical agreement configuration prevail, can undertake non-standard customization. | |||||
Moving Direction Of Mecanum Wheel
-
