Flat Q235 Battery Powered 15 Ton Coil Transfer Cart
| Place of Origin | Henan, China |
|---|---|
| Brand Name | BEFANBY |
| Certification | CE, SGS, ISO9001 |
| Model Number | coil |
| Minimum Order Quantity | 1 set/sets |
| Packaging Details | The transfer car will be packed by the tarp, the parts will be shipped in the high quality wooden case. |
| Delivery Time | 40-50 days as usual delivery,30-40 days for urgent delivery |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 800 sets per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| After-sales Service Provided | Engineers Available To Service Machinery Overseas | Warranty | 2 Years |
|---|---|---|---|
| Application | Steel Coil Transfer Workshop ,pmetal Coil, Paper Coil, Industrial Cable Drum, Material Handling Automation | Capacity | 1-1000 Ton For Steel Coil Car |
| Power Supply | Battery Power/customized | Product Name | Heavy Duty Flat Aluminum Steel Coil Railway Trolley 15 Ton Battery Powered |
| Material | Q235 | Operation Type | Hand Pendant + Remote Control |
| Color | Yellow, Gray, Red Or As Your Needs | Port | Qingdao, Tianjin, Shanghai |
| Safe Parts | Sound And Light Alarm, Lamp, E-stop, Dead Man Stop... | Custom Function | Hydraulic Lifting Device |
| Table Size | Custom Platform Of Coil Handling Equipment | ||
| Highlight | 15 Ton Coil Transfer Cart,Q235 Coil Transfer Cart,Flat Coil Transfer Trolley |
||
Product Description
Heavy Duty Flat Aluminum Steel Coil Railway Trolley 15 Ton Battery Powered
1. Product Profile
Custom 25 ton rail coil transfer trolley with sound and light alarm can be applied in transporting steel coils, aluminum coil, paper coil, roller, oil tank and pipes for plant. This battery operated coil transfer trolley can be designed to be an extremely cost effective, safe and flexible load moving alternative. The V shape/ U shaped supporting and roller can be mounted to avoiding the coil fall from the trolley.
The heavy duty flat aluminum steel coil railway trolley 15 ton is battery powered,so it can be easy operation.You can also choose the supply power ways according to your requirements.Such as:battery powered,rail motorized,cable reel powered,etc.The heavy duty flat aluminum steel coil railway trolley 15 ton is widely used combined with the crane.
|
Advantage
|
|
1.The mounted remote controller controls the whole vehicle , the remote controller has horn , forward , backward , fast forward , rewind , braking , etc . heavy duty material handling equipment. 2.Battery powered and equipped the alarm light. 3.Micro-moving traction. Heavy duty material handling equipment-rail truck trailer has parking braking function to ensure that the ramp does not slip, and has manual parking brake clutch function. 4.Angle box is a maskant for the coil transfer wheels. 5.The charging wire not less than 15m, with automatic wiring arrangement, retracts. 7.The capacity and table size can be customized. 8.Special countertop waterproof material design for the platform.
|
Technique Parameter
| Model | KPX-5t | KPX-20t | KPX-25t | KPX-40t | KPX-80t | KPX-150t | |
| Rated Load | 5 | 20 | 25 | 40 | 80 | 150 | |
| Table size | Length(L) | 3500 | 4000 | 4500 | 5000 | 6000 | 10000 |
| Width(W) | 2000 | 2200 | 2200 | 2500 | 2600 | 3000 | |
| Height(H) | 500 | 550 | 600 | 650 | 800 | 1200 | |
| Wheel Base | 2500 | 2800 | 3200 | 3800 | 4700 | 7000 | |
| Rail Inner Gauage | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | |
| Wheel Diameter | 300 | 350 | 400 | 500 | 600 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance | 50 | 50 | 50 | 50 | 75 | 75 | |
| Running Speed | 25 | 20 | 20 | 20 | 20 | 18 | |
| Motor Power | 1.2 | 3 | 3.5 | 5 | 10 | 15 | |
| Battery Capacity | 180 | 180 | 250 | 300 | 400 | 600 | |
| Battery Voltage | 36 | 48 | 48 | 48 | 72 | 72 | |
| Running Time When Full Load | 5.4 | 4 | 4 | 3.6 | 3.6 | 2.9 | |
| Max Wheel Load | 25.8 | 77.7 | 94.5 | 142.8 | 278.4 | 265.2 | |
| Reference Weight | 3.6 | 5.9 | 6.5 | 7.6 | 12.8 | 26.8 | |
| Recommended Rail Model | P18 | P24 | P38 | P43 | P50 | QU100 | |
2. Our Company
Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd is a collection of research, design, manufacture, installation and after-sales service of electric handling bogie ,transfer carts as one of the professional manufacturing company, which has a modernized management team and excellent staff.And our prodcuts gets CE, SASO,SGS,ISO certificate and other 8 national patent, our products have been exported to more than 40 countries and regions,such as Germany, Mexico, USA, Turkey, South Africa, Singapore etc.
Our team
You can copy the following options to select your specific requirement for the transfer car to send us. And then the proper solution and price will be sent to you.
1. The load capacity of the transfer car is ( ) ton.
2. The table size is ( ) mm (L) * ( ) mm (W)*( ) mm (H).
3. The voltage is ( ) V, ( ) HZ, 3 phase.
4. The running time is ( ) hours per day.
5. The running distance is ( ) m per time.
6. The transfer cart runs on the rails or common floor?
7. Whether exist turning?
8. Whether has other special requirement?
