50t large capacity rail transfer carriage for assembly line
| Place of Origin | Xinxiang |
|---|---|
| Brand Name | BEFANBY |
| Certification | CE,SGS,ISO9001 |
| Model Number | KPC-50T |
| Minimum Order Quantity | 1 set |
| Price | Negotiation |
| Packaging Details | Electrical parts will add shields. As required by the customer, we can add a fixed packing. |
| Delivery Time | 50-60 days as usual delivery,40-50days for urgent delivery |
| Payment Terms | 30% deposit by T/T in advance, 70%balance by T/T before dispatch |
| Supply Ability | 600 sets one year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Power Supply Mode | Busbar Power | Application | Heavy Industry |
|---|---|---|---|
| Car Size | Can Be Customised | Load Capacity | Up To 300 Ton |
| Electrical Parts | Siemens, Schneider, Nord | Saftey Devices | Warning Lamp, Siren, Bumper |
| Exported Countries | South Africa, Australia, Syria | Product Name | 50t Large Capacity Rail Transfer Carriage For Assembly Line |
| Wheel Diameter(mm) | 400 | Rail Gauge(mm) | 1435 |
| Wheel Quantity | 4 Pcs | Contact | Marketing@bfbhandling.com |
| Highlight | industrial material handling carts,warehouse handling equipments |
||
Product Description
50t large capacity rail transfer carriage for assembly line
Working of rail transfer carriage
Rail transfer carriage is very popular with the customers for assembly line. This kind of rail transfer carriage is power by busbar(electric sliding line). It gets power from sliding line durning the cart running. The electric control system of the cart realize it start, stop, go forward and backward. It is suitable to applied in production line or assembly line, to transfer heavy material or parts, the distance is better to less than 50m.
Advantages of rail transfer carriage
- Box girder structure, not easy to deform
- simple structure, low cost
- no strict requires on rails
- can be applied high using frequency condition
- can be used in high-temperature environment
- can be used in explosion-proof environment
Main Parts of rail transfer carriage
Production of rail transfer carriage
Technical parameters of rail transfer carriage
Model | KPC-2T | KPC-10T | KPC-20T | KPC-30T | KPC-50T | KPC-63T | KPC-150T | |
| Rated load (T) | 2 | 10 | 20 | 30 | 50 | 63 | 150 | |
| Table size | length(L) | 2000 | 3600 | 4000 | 4500 | 5500 | 5600 | 10000 |
| Width(W) | 1500 | 2000 | 2200 | 2200 | 2500 | 2500 | 3000 | |
| Height(H) | 450 | 500 | 550 | 600 | 650 | 700 | 1200 | |
| Wheel Base (mm) | 1200 | 2600 | 2800 | 3200 | 4200 | 4300 | 7000 | |
| Rail Inner Gauge (mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 2000 | |
| Wheel Diameter(mm) | Φ270 | Φ300 | Φ350 | Φ400 | Φ500 | Φ600 | Φ600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 75 | 75 | |
| Running speed (min) | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power (Kw) | 1 | 1.6 | 2.2 | 3.5 | 5 | 6.3 | 15 | |
| Battery Capacity(Ah) | 180 | 160 | 180 | 250 | 330 | 400 | 600 | |
| Battery Voltage(V) | 24 | 48 | 48 | 48 | 48 | 48 | 72 | |
| Running Time When Full Load | 4.32 | 4.8 | 4 | 3.5 | 3.3 | 3 | 2.9 | |
| Running Distance for one Charge(Km) | 6.5 | 7.2 | 4.8 | 4.2 | 4 | 3.6 | 3.2 | |
| Max Wheel Load (KN) | 14.4 | 42.6 | 77.7 | 110.4 | 174 | 221.4 | 265.2 | |
| Reference Weight (t) | 2.8 | 4.2 | 5.9 | 6.8 | 8 | 10.8 | 26.8 | |
| Recommended Rail Model | P15 | P18 | P24 | P38 | P43 | P50 | QU100 | |
Application of rail transfer carriage
