Battery Operated Hydraulic Lifting System Steel Coil Trailers Material Handling Equipment
| Place of Origin | Henan,China |
|---|---|
| Brand Name | BEFANBY |
| Certification | CE,SGS,ISO9001 |
| Model Number | KPX |
| Minimum Order Quantity | 1 set/sets |
| Price | Negotiation |
| Packaging Details | The transfer cart will be packed by the tarp, the parts will be shipped in the high quality wooden case. |
| Delivery Time | 40-50 days as usual delivery,30-40 days for urgent delivery |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 600 set/sets, per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Battery Operated Hydraulic Lifting System Steel Coil Trailers Material Handling Equipment | Color | Customized |
|---|---|---|---|
| Application | Industrial Field | Running Speed | 0-20m/min |
| Running Distance | Unlimited | Warranty | 12 Months |
| Port | Qingdao/Tianjin/Shanghai | Load Capacity | 1-500T |
| Operation Type | Hand Pendant + Remoete Control | Power Supply | Battery Powered |
| Highlight | hydraulic scissor lift trolley,automated material handling equipment |
||
Product Description
Battery operated hydraulic lifting system steel coil trailers material handling equipment
1. The Introduce of Battery operated hydraulic lifting system steel coil trailers material handling equipment
The Battery operated hydraulic lifting system steel coil trailers material handling equipment can be turned in the order of magnitude .Adding PLC ,the program is better ,the performance is stronger.The Battery operated hydraulic lifting system steel coil trailers material handling equipment was developed to dramatically reduce the material handling requirements of cranes and fork trucks while providing quick, safe and smooth movement of materials and/or products through manufacturing facilities. track traverser construction is based on our world renowned lifting trolley and provides controlled movement of heavy and oversized loads such as dies, coils and work in progress. Our Battery operated hydraulic lifting system steel coil trailers material handling equipmentis available in a number of configurations specifically designed to suit the needs of our customers.
For coil transfer trailer BEFANBY manufactured, The V-frame can be added to prevent the coil products from slipping off the platform. Of course, we can customize the structure of the car according to the placement of the coil products and the number of couls to be placed.
2. Working Principles of Battery operated hydraulic lifting system steel coil trailers material handling equipment
This kind of Battery operated hydraulic lifting system steel coil trailers material handling equipment is powered by Maintenance free battery , The battery is installed in the cart, and supply DC electricity to the control system, which makes the cart start, stop, go forward, back forward and so on.It is consist of Maintenance free battery, motor, reducer, cart frame, rail wheel, electric appliance, operation handle, remote control, etc.
3. Details Manufacture of Battery operated hydraulic lifting system steel coil trailers material handling equipment
4. Technique Parameter of Battery operated hydraulic lifting system steel coil trailers material handling equipment
| Model | KPX-2t | KPX-5t | KPX-10t | KPX-16t | KPX-20t | KPX-25t | KPX-30t | KPX-40t | KPX-50t | KPX-63t | KPX-80t | KPX-100t | KPX-150t | |
| Rated Load | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
| Table size | Length(L) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
| Width(W) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 | |
| Height(H) | 450 | 500 | 500 | 550 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 | |
| Wheel Base | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
| Rail Inner Gauage | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
| Wheel Diameter | 270 | 300 | 300 | 350 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
| Running Speed | 25 | 25 | 25 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 18 | |
| Motor Power | 1 | 1.2 | 2 | 2.2 | 3 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 | 15 | |
| Battery Capacity | 180 | 180 | 160 | 180 | 180 | 250 | 250 | 300 | 330 | 400 | 400 | 440 | 600 | |
| Battery Voltage | 24 | 36 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 | |
| Max Wheel Load | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
| Reference Weight | 2.8 | 3.6 | 4.2 | 5.5 | 5.9 | 6.5 | 6.8 | 7.6 | 8 | 10.8 | 12.8 | 14.6 | 26.8 | |
| Recommended Rail Model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | P50 | QU100 | QU100 | |
5.Transportation solution of 50t railway transfer cart, gearmotor battery powered factory industry transfer rail cart
|
Firstly, BEFANBY 50t railway transfer cart, gearmotor battery powered factory industry transfer rail cart not only have sold across the country, but also exported to US, Canada, Thailand, Netherlands, South Africa, UAE, Turkey, Saudi Arabia etc.
Secondly, The 50t railway transfer cart, gearmotor battery powered factory industry transfer rail cart is packed with tarp, and the wheel , rails and parts of the industrial material handling robust railcar will be packed by the high quality wooden case.
Thirdly, According the table size and quantity, the industrial material handling robust railcar would be transported to clients by FCL, LCL, Bulk Transportation, Open Top Container, Flat Rack Container and so on.
|
6. BEFANBY Company
Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd is a collection of research, design, manufacture, installation and after-sales service of electric handling bogie ,transfer carts as one of the professional manufacturing company, which has a modernized management team and excellent staff.And 50 countries and regions,such as Germany, Mexico, USA, Turkey, South Africa, Singapore etc.
