20T Steel Pipe Battery Transfer Cart Lifting With Rail Wheel
| Place of Origin | Henan,China |
|---|---|
| Brand Name | BEFANBY |
| Certification | CE,SGS,ISO9001 |
| Model Number | KPX |
| Minimum Order Quantity | 1 set/sets |
| Price | Negotiation |
| Packaging Details | The rail wheel transfer car will be packed by the tarp, the parts will be shipped in the high quality wooden case. |
| Delivery Time | 40-50 days as usual delivery,30-40days for urgent delivery |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 800 set/sets, per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Q235 | Color | Customized |
|---|---|---|---|
| Application | Industrial Field, Steel Plant，Steel Pipe Transport | Running Speed | 0-20m/min |
| Running Distance | Unlimited | Warranty | 24 Months |
| Port | Qingdao/Tianjin/Shanghai | Load Capacity | 1-1000 Ton Payload |
| Operation Type | Hand Pendant + Remote Control | Power Supply | Battery Powered |
| Advantage | More Than 17 Years' Experience For Transporting Sections Of Vessel Between Buildings Of Shipyard | Option Power | Cable Power Supply, Trolly Line, Low Voltage Rail, Diesel, Etc. |
| High Light | Lifting Forklift Battery Transfer Cart,Pallet Transfer Carts Rail Wheel,Battery Powered Cart 20T |
||
Product Description
20T Steel Pipe Transport Rail Wheel Transfer Car With Lifting
Rail wheel transfer car is an advanced electric transfer cart transport vehicle for short distance construction in enterprises, which can effectively solve the freight transportation between workshops. it is mainly composed of four-wheel steering system, battery, dc motor, high-voltage bearing, lifting device, cart body frame, driving control device, electrical components, etc. the whole frame is easy to split and transport. rail wheel transfer car has the characteristics of smooth driving, easy lifting control, large torque, large bearing capacity and long service life. it is widely used in equipment manufacturing, mining, machinery, heavy industry and textile light industry. in the use of rail wheel transfer car, it has the advantages of simple operation, easy to move, maintenance and not limited by the distance, low noise, strong power, strong bearing capacity, strong mobility, large traction, and can operate normally in harsh environment. in the construction process, the hydraulic lifting rail wheel transfer car not only has high safety performance, but also is easy to operate and master, which can effectively improve the work efficiency and reduce the construction cost.
Technique Parameter
| Model | KPX-10t | KPX-16t | KPX-25t | KPX-30t | KPX-40t | KPX-50t | KPX-63t | KPX-80t | KPX-100t | KPX-150t | |
| Rated Load | 10 | 16 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
| Table size | Length(L) | 3600 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
| Width(W) | 2000 | 2000 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 | |
| Height(H) | 500 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 | |
| Wheel Base | 2600 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
| Rail Inner Gauage | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
| Wheel Diameter | 300 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
| Running Speed | 25 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 18 | |
| Motor Power | 2 | 2.2 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 | 15 | |
| Battery Capacity | 160 | 180 | 250 | 250 | 300 | 330 | 400 | 400 | 440 | 600 | |
| Battery Voltage | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 | |
| Max Wheel Load | 42.6 | 64.5 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
| Reference Weight | 4.2 | 5.5 | 6.5 | 6.8 | 7.6 | 8 | 10.8 | 12.8 | 14.6 | 26.8 | |
Application
Transporting Cargoes: the rail transfer car is suitable for various industries, steel mill, transfer steel products such as steel structure, steel pipe, steel billets, steel ladle and coil, etc.
From one location to another; paper roll plant: transfer paper coil painting shops: transfer work piece into the painting room sand blasting room other industries: shipbuilding, quarries, warehouses and multi-bay workshops, etc
All can be customized as per customers’ requirement.And BEFANBY business is meeting your business need, hope our professional team can help you well with rich experience.
battery powered transfer cart rail power supply trolley line motorized rail cart cable power supply
Detailed Images of Injection Mold Plant Battery Power Rail Transfer Die Cart 30 Ton Factory
battery powered transfer cart rail power supply trolley line motorized rail cart cable power supply
