Light Duty Battery Operate Travel Cart With Dc Motor 5 Ton
| Place of Origin | Henan,China |
|---|---|
| Brand Name | BEFANBY |
| Certification | CE,SGS,ISO9001 |
| Model Number | KPX-5T |
| Minimum Order Quantity | 1 set/sets |
| Price | Negotiation |
| Packaging Details | The battery operate travel cart will be packed by the tarp, the parts will be shipped in the high quality wooden case. |
| Delivery Time | 40-50 days as usual delivery,30-40days for urgent delivery |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 1500 set/sets, per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Color | Customized | Application | Industrial Field, Battery Operate Transfer |
|---|---|---|---|
| Warranty | 24 Months | Port | Qingdao/Tianjin/Shanghai |
| Load Capacity | 1-1500 Ton Payload,5t Capacity Support | Operation Type | Hand Pendant + Remote Control |
| High Light | Battery Operated Travel Cart 5 Ton,Customized Dc Motor Battery Transfer Cart,5 Ton Industrial Field Travel Cart |
||
Product Description
Light Duty Battery Operate Travel Cart With Dc Motor 5t
The battery operate travel cart is an electric driven material transfer cart which is running on the rails. it is designed for workshop material handling from one bay to another in the working site.
as the battery operate travel carts are equipped with steel wheels and transfer on steel rails, and the very low friction between steel and steel, the battery operate travel carts are suited to very heavy loading capacities.
1. almost complete absence of maintenance
2. increase in travel cart's useful life periods (the replacement of an electric motor is very simple and cheap)
3. huge decrease in noise pollution
4. possibility of automation.
Operation Guidance
|
The workers who operate the battery travel cart need to be familiar with the structural performance of the equipment and can operate independently only after passing the test. when transferring heavy objects, they should be placed stably and gently to promise uniform weight distribution, and the equipment shall not be used beyond the specification or overload. when changing the running direction during working, the reverse start can be transfered out only after the movement stops. the operator of battery operate travel cart shall also inspect the equipment of electric travel cart according to relevant inspection requirements.
|
Technique Parameter
| Model | KPX-10t | KPX-16t | KPX-25t | KPX-30t | KPX-40t | KPX-50t | KPX-63t | KPX-80t | KPX-100t | KPX-150t | |
| Rated Load | 10 | 16 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
| Table size | Length(L) | 3600 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
| Width(W) | 2000 | 2000 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 | |
| Height(H) | 500 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 | |
| Wheel Base | 2600 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
| Rail Inner Gauage | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
| Wheel Diameter | 300 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
| Running Speed | 25 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 18 | |
| Motor Power | 2 | 2.2 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 | 15 | |
| Battery Capacity | 160 | 180 | 250 | 250 | 300 | 330 | 400 | 400 | 440 | 600 | |
| Battery Voltage | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 | |
| Max Wheel Load | 42.6 | 64.5 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
| Reference Weight | 4.2 | 5.5 | 6.5 | 6.8 | 7.6 | 8 | 10.8 | 12.8 | 14.6 | 26.8 | |
All can be customized as per customers’ requirement.And BEFANBY business is meeting your business need, hope our professional team can help you well with rich experience.
