Fine Quality Electric Motorized 12 Ton Railway Trolley
Place of Origin | Henan,China |
---|---|
Brand Name | BEFANBY |
Certification | CE,SGS,ISO9001 |
Model Number | KPX |
Minimum Order Quantity | 1 set/sets |
Price | Negotiation |
Packaging Details | The railway trolley will be packed by the tarp, the parts will be shipped in the high quality wooden case. |
Delivery Time | 40-50 days as usual delivery,30-40days for urgent delivery |
Payment Terms | L/C, T/T, Western Union |
Supply Ability | 1500 set/sets, per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xColor | Customized | Application | Workshop, Steel Factory, Production Line,Billet Industry |
---|---|---|---|
Running Speed | 0-20m/min | Load Capacity | 1-1500 Ton Payload |
Power Supply | Battery Powered | Product Name | Fine Quality Electric Motorized 12 Ton Railway Trolley |
Material | Steel | ||
High Light | Workshop Electric Railway Trolley,12 Ton Motorized Railway Trolley,Motorized Transfer Cart 20m/min |
Fine Quality Electric Motorized 12 Ton Railway Trolley
Product Description Of Fine Quality Electric Motorized 12 Ton Railway Trolley
In order to efficiently move materials from one location to another, the choice of transportation equipment is crucial. In many industrial fields, the heavy load electric railway trolley moving on the track is undoubtedly a very ideal choice.
Heavy duty electric railway trolley is a kind of electric transport vehicle that can drive on the prescribed track. Using batteries as a power source, it can efficiently transport heavy materials without manual control. Such vehicles usually consist of a frame, wheels, power system, control system, etc.
First, its frame is usually made of strong and durable steel to withstand heavy load pressure. The design of the frame also takes into account the various sizes and weights of the materials to be transported to ensure the stability and safety of the flat car.
The cast steel wheels ensure the smooth running of the flat car on the track, and improve the running efficiency and stability of the flat car.
The power system is the power source of the heavy-duty electric flat car. It usually consists of a battery, a motor, and a transmission device. The choice of battery largely determines the endurance and service life of the flat cart. The high efficiency and energy saving motor and transmission device can provide enough power, so that the flat car can smoothly move the heavy load material.
Control system is the intelligent core of heavy duty electric flat car. It controls the motion of the railway trolley through various sensors and programs. For example, by installing distance sensors, the control system is able to monitor the distance between the flat car and its surroundings in real time to avoid collisions. At the same time, the control system can also adjust the running speed and power output of the flat car according to the weight and size of the transported materials, so as to achieve the best transportation effect.
The advantage of heavy duty electric railway trolley lies in their ability to effectively respond to transportation needs in various industrial scenarios. Whether in the manufacturing industry, logistics industry or ports and terminals and other places, heavy duty electric flat car can be competent. They can drive freely on fixed tracks and shuttle between different working areas to achieve fast and safe movement of materials.
In short, the heavy duty electric railway trolley is a very ideal transportation equipment, which is suitable for material transportation tasks in various industrial scenarios. They have strong and durable frames, efficient and stable walking parts, reliable and efficient power systems and intelligent control systems. By using heavy-duty electric railway trolley, enterprises can improve the efficiency and safety of material transportation, injecting strong power into the production process.
Product Details Of Fine Quality Electric Motorized 12 Ton Railway Trolley
Product Parameter Of Fine Quality Electric Motorized 12 Ton Railway Trolley
Model | KPX-10t | KPX-16t | KPX-25t | KPX-30t | KPX-40t | KPX-50t | KPX-63t | KPX-80t | KPX-100t | KPX-150t | |
Rated Load | 10 | 16 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
Table size | Length(L) | 3600 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
Width(W) | 2000 | 2000 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 | |
Height(H) | 500 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 | |
Wheel Base | 2600 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
Rail Inner Gauage | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
Wheel Diameter | 300 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 | |
Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
Ground Clearance | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
Running Speed | 25 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 18 | |
Motor Power | 2 | 2.2 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 | 15 | |
Battery Capacity | 160 | 180 | 250 | 250 | 300 | 330 | 400 | 400 | 440 | 600 | |
Battery Voltage | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 | |
Max Wheel Load | 42.6 | 64.5 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
Reference Weight | 4.2 | 5.5 | 6.5 | 6.8 | 7.6 | 8 | 10.8 | 12.8 | 14.6 | 26.8 |
