4 Axles 5 Ton Battery Railway Transfer Trolley
Place of Origin | Henan,China |
---|---|
Brand Name | BEFANBY |
Certification | CE,SGS,ISO9001 |
Model Number | KPX-15T |
Minimum Order Quantity | 1 set/sets |
Price | Negotiation |
Packaging Details | The material transfer cart will be packed by the tarp, the parts will be shipped in the high quality wooden case. |
Delivery Time | 40-50 days as usual delivery,30-40days for urgent delivery |
Payment Terms | L/C, T/T, Western Union |
Supply Ability | 1500 set/sets, per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xColor | Customized | Application | Workshop,machinery Industry, Assembly Line,Billet Industry |
---|---|---|---|
Running Speed | 0-20m/min | Load Capacity | 1-1500 Ton |
Power Supply | Battery Powered | Product Name | 4 Axles 5 Ton Battery Railway Transfer Trolley |
Material | Steel | ||
High Light | 5Ton Battery Railway Transfer Trolley,4 Axles Battery Railway Transfer Trolley,Battery Railway Transfer Trolley |
4 Axles 5 Ton Battery Railway Transfer Trolley
Product Description
As a cart that uses batteries as its power source and can be flexibly used in explosion-proof situations, it provides efficient and convenient material transportation solutions for factories, chemical plants and other occasions.
First of all, rail electric transfer carts have a high degree of safety and stability. Because it is powered by batteries. At the same time, this design also ensures the safe use of the flat car in explosion-proof situations. Many chemical plants and hazardous materials warehouses require tools to be explosion-proof to reduce the risk of accidents.
Secondly, the rail electric transfer cart has flexible turning performance. By adopting a unique rail design and sophisticated control system, the transfer cart can turn freely in a small space and achieve precise guidance.
In addition, the rail electric transfer cart also has a series of intelligent functions. Modern transfer cart are equipped with advanced navigation systems and automatic obstacle avoidance devices, which can plan their own paths and avoid collisions. At the same time, it can also realize intelligent monitoring and scheduling of material transportation through data interaction with the warehouse management system.
Product Details
Product Parameter
Model | KPX-10t | KPX-16t | KPX-25t | KPX-30t | KPX-40t | KPX-50t | KPX-63t | KPX-80t | KPX-100t | KPX-150t | |
Rated Load | 10 | 16 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
Table size | Length(L) | 3600 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
Width(W) | 2000 | 2000 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 | |
Height(H) | 500 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 | |
Wheel Base | 2600 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
Rail Inner Gauage | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
Wheel Diameter | 300 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 | |
Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
Ground Clearance | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
Running Speed | 25 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 18 | |
Motor Power | 2 | 2.2 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 | 15 | |
Battery Capacity | 160 | 180 | 250 | 250 | 300 | 330 | 400 | 400 | 440 | 600 | |
Battery Voltage | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 | |
Max Wheel Load | 42.6 | 64.5 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
Reference Weight | 4.2 | 5.5 | 6.5 | 6.8 | 7.6 | 8 | 10.8 | 12.8 | 14.6 | 26.8 |
