Steel Plant Battery Powered Carts Industrial , 30T Motorized Rail Cart

Place of Origin Xinxiang
Brand Name BEFANBY
Certification CE,SGS,ISO9001
Model Number KPJ-30T transfer trolley
Minimum Order Quantity 1 set
Price Negotiation
Packaging Details Electrical parts will add shields. As required by the customer, we can add a fixed packing.
Delivery Time 50-60 days as usual delivery,40-50days for urgent delivery
Supply Ability 60 sets per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Peoduct Name 30t Steel Plant Apply Electric Motorised Transfer Trolley On Steel Rail Capacity(t) 20t
Table Size(mm) 4000*2200*600 Running Speed(m/min) 0-25
Running Distance(m) 100 Rail Type P24
Wheel Pressure(KN) 77.7 Rail Gauge(mm) 1435
Wheel Diameter(mm) 300 Wheel Quantity(pcs) 4
Weight(t) 5.9 Certificate CE, SGS, ISO9001, SASO
Package The Whole Cart Is Packed By High Quality Plastic Cloth Color Red, Yellow, Blue
High Light

motorized industrial carts

,

motorised trolleys carts

Leave a Message
Product Description

30t steel plant apply electric motorised transfer trolley on steel rail



This kind of steel motorised transfer trolley is running on steel rails or steel squre bars.It is commonly applied in steel plant, aluminum factory, plastic pipes factory, etc to transfer rounded material, from producing line to store. The power supply of the motorised transfer trolley can be customized, we can recommend client a suitable type according to their working site, It can be storage battery power, cable drum power, Busbar power, conductor rail power, towed cable power etc.

The 30t transfer trolley is cable drum powered, the cable drum is installed at the bottom of the rail cart.



Features of motorised transfer trolley

  • Large load capacity is up to 300t;
  • Has no limit on using time
  • Has no limit on using frequency
  • The V-shaped device, hydraulic lifting device can be added on the platform;
  • With remote control, push button is available;
  • Maximum safety to the operator;
  • Has no strict requirement on rail installation
  • Warranty period: one year;
Photo show of motorised transfer trolley


4

3

Application of motorised transfer trolley

Assembly line: Due to advantage of without cable, it is mainly applied in assembly line, can realize the straight rail, S shape rail, U shape rail, C shape rail, Arc-shaped rail, 90 degree turn rail, crossing rail etc.
Metallurgy industry: With the functions of steady traveling, stepless speed regulation, the cart is commonly applied to transfer steel ladle, aluminum ladle, lead ladle, steel slag etc. Generally the outer surface temperature of the ladle is 200-300 degree , due to the high temperature, the cart should be designed with heat exposure proof device, expecially to the battery, motor, reducer and electric appliance.
Ship industry: Due to the large load capacity, the cart is applied in ship industry to transfer workpieces, maintenance tools(propeller, motor etc.). The cart is also applied in dock or harbor to transfer cargoes and containers. If needed, the hydraulic lifting device , weighing device and automatic device can be added.



The motorised transfer trolleyis applied in metal industry factory to transfer large dimension steel plate, steel structure. The transport bogie is remote control, it is convenient to operate.

It is suitable to application with not so long running distance, high using frequency. It has no time limit.


Steel Plant Battery Powered Carts Industrial , 30T Motorized Rail Cart 2

Steel Plant Battery Powered Carts Industrial , 30T Motorized Rail Cart 3

The main parts of steel plant motorised transfer trolley is cart frame, motor, reducer, cable drum, electric appliance, etc.

These kind of motorised transfer trolley is applied to transfer heavy steel or aluminum coils. In order to inviod the steel coils falling down from the transfer cart, we designed a V-frame. It can protect the coils also the security. We can recommend you the direction of the V-frame according to the coils.



The parameter of motorised transfer trolley
Model
KPJ-2T KPJ-10T KPJ-20T KPJ-30T KPJ-50T KPJ-63T KPJ-150T
Rated load (T) 2 10 20 30 50 63 150
Table size length(L) 2000 3600 4000 4500 5500 5600 10000
Width(W) 1500 2000 2200 2200 2500 2500 3000
Height(H) 450 500 550 600 650 700 1200
Wheel Base (mm) 1200 2600 2800 3200 4200 4300 7000
Rail Inner Gauge (mm) 1200 1435 1435 1435 1435 1435 2000
Wheel Diameter(mm) Φ270 Φ300 Φ350 Φ400 Φ500 Φ600 Φ600
Wheel Quantity 4 4 4 4 4 4 8
Ground Clearance (mm) 50 50 50 50 50 75 75
Running speed (min) 0-25 0-25 0-20 0-20 0-20 0-20 0-18
Motor Power (Kw) 1 1.6 2.2 3.5 5 6.3 15
Battery Capacity(Ah) 180 160 180 250 330 400 600
Battery Voltage(V) 24 48 48 48 48 48 72
Running Time When Full Load 4.32 4.8 4 3.5 3.3 3 2.9
Running Distance for one Charge(Km) 6.5 7.2 4.8 4.2 4 3.6 3.2
Max Wheel Load (KN) 14.4 42.6 77.7 110.4 174 221.4 265.2
Reference Weight (t) 2.8 4.2 5.9 6.8 8 10.8 26.8
Recommended Rail Model P15 P18 P24 P38 P43 P50 QU100



BEFANBY Company




Steel Plant Battery Powered Carts Industrial , 30T Motorized Rail Cart 4

Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd is a professional and experienced manufacturer,exporter of material transfer car in China, meanwhile we also design material handling solution according to client's demand

Cutomer from worldwide


Steel Plant Battery Powered Carts Industrial , 30T Motorized Rail Cart 5

Parts of BEFANBY Certificates


Steel Plant Battery Powered Carts Industrial , 30T Motorized Rail Cart 6

Delivery of motorised transfer trolley


Steel Plant Battery Powered Carts Industrial , 30T Motorized Rail Cart 7

Generally the motorised transfer trolley is delivery through container. If the dimension of the transport is too large, it

can be break up or delivery through flat rack.

BEFANBY advantages
  • Our commitment: The load bearing safety factor of the trolley is no less than 120%.
  • Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.
  • 16 hours engineering service and 24 hours internet service for our customers.
  • During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.
  • Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.
