OEM Dc Motor 50T Hydraulic Lifting Transfer Cart Steerable
| Place of Origin | Xinxiang |
|---|---|
| Brand Name | BEFANBY |
| Certification | CE,SGS,ISO9001 |
| Model Number | KPX-50 ton |
| Minimum Order Quantity | 1 set |
| Price | Negotiation |
| Packaging Details | Electrical parts will add shields. As required by the customer, we can add a fixed packing. |
| Delivery Time | 40-50 days as usual delivery,30-40days for urgent delivery |
| Payment Terms | L/C, T/T |
| Supply Ability | 100 sets per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Peoduct Name | Battery Powered 50 Ton Lifting Rail Car | Capacity(t) | 1-1000 Tons |
|---|---|---|---|
| Package | The Whole Cart Is Packed By High Quality Plastic Cloth | Color | Red, Yellow, Blue |
| Operation Type | Hand Pendant+ Remote Control | After-sales Service Provided | Field Maintenance And Repair Service |
| Warranty | 2 Years | Running Speed | 0-20m/min |
| Motor | Dc Motor | Power Source | Battery Powered |
| Application | Steel, Aluminum Coil, Roller, Cylinder Transfer | OEM | Accept |
| High Light | 50T Hydraulic Lifting Transfer Cart,OEM Hydraulic Lifting Transfer Cart,Steerable Hydraulic Lifting Transfer Cart |
||
Product Description
Battery Powered 50 Ton Lifting Rail Car
50ton lifting rail car is an advanced electric flat car transport vehicle for short distance construction in enterprises, which can effectively solve the freight transportation between workshops. it is mainly composed of four-wheel steering system, storage battery, ac motor, high-voltage bearing, lifting device, car body frame, driving control device, electrical components, etc. the whole frame is easy to split and transport. hydraulic lifting electric rail car has the characteristics of smooth driving, easy lifting control, large torque, large bearing capacity and long service life. it is widely used in equipment manufacturing, mining, machinery, heavy industry and textile light industry. in the use of hydraulic lifting electric transfer trolley, it has the advantages of simple operation, easy to move, maintenance and not limited by the distance, low noise, strong power, strong bearing capacity, strong mobility, large traction, and can operate normally in harsh environment. in the construction process, the hydraulic synchronous lifting electric mold transfer cart not only has high safety performance, but also is easy to operate and master, which can effectively improve the work efficiency and reduce the construction cost.
| Model | KPX-2T | KPX-10T | KPX-20T | KPX-30T | KPX-50T | KPX-63T | KPX-150T | |
| Rated load (T) | 2 | 10 | 20 | 30 | 50 | 63 | 150 | |
| Table size | length(L) | 2000 | 3600 | 4000 | 4500 | 5500 | 5600 | 10000 |
| Width(W) | 1500 | 2000 | 2200 | 2200 | 2500 | 2500 | 3000 | |
| Height(H) | 450 | 500 | 550 | 600 | 650 | 700 | 1200 | |
| Wheel Base (mm) | 1200 | 2600 | 2800 | 3200 | 4200 | 4300 | 7000 | |
| Rail Inner Gauge (mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 2000 | |
| Wheel Diameter(mm) | Φ270 | Φ300 | Φ350 | Φ400 | Φ500 | Φ600 | Φ600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 75 | 75 | |
| Running speed (min) | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power (Kw) | 1 | 1.6 | 2.2 | 3.5 | 5 | 6.3 | 15 | |
| Battery Capacity(Ah) | 180 | 160 | 180 | 250 | 330 | 400 | 600 | |
| Battery Voltage(V) | 24 | 48 | 48 | 48 | 48 | 48 | 72 | |
| Running Time When Full Load | 4.32 | 4.8 | 4 | 3.5 | 3.3 | 3 | 2.9 | |
| Running Distance for one Charge(Km) | 6.5 | 7.2 | 4.8 | 4.2 | 4 | 3.6 | 3.2 | |
| Max Wheel Load (KN) | 14.4 | 42.6 | 77.7 | 110.4 | 174 | 221.4 | 265.2 | |
| Reference Weight (t) | 2.8 | 4.2 | 5.9 | 6.8 | 8 | 10.8 | 26.8 | |
| Recommended Rail Model | P15 | P18 | P24 | P38 | P43 | P50 | QU100 | |
Application
Battery powered 50 ton lifting rail car is mainly applied in steel factory (steel bar, steel billet, steel plate, steel coil, steel pipe, section steel, steel structure), production line (raw material handling, finished products transportation), metallurgy industry (steel ladle, scrap ladle), warehouse transport, mold plant (dies, molds transport from one bay to another), ship industry (steel parts transfer, maintenance, assemble, container transport), workpieces transport in workshop, lathe transport, construction (bridge, simple building, concrete, concrete column), energy (poly crystalline silicon, generator, windmill), chemical industry (electrolytic cell, retort, equipment transport), etc.
BEFANBY Company
Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd is a professional and experienced manufacturer,exporter of material transfer car in China, meanwhile we also design material handling solution according to client's demand
Cutomer from worldwide
BEFANBY advantages
- Our commitment: The load bearing safety factor of the trolley is no less than 120%.
- Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.
- 16 hours engineering service and 24 hours internet service for our customers.
- During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.
- Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.
