Cable Drum Power Rail Transfer Cart 250 Ton For Material Load

Place of Origin Xinxiang City, Henan Province
Brand Name BEFANBY
Certification CE,SGS,ISO9001
Model Number KPJ-1-500t
Packaging Details The rail transfer cart will be packed by the tarp, the parts will be shipped in the high quality wooden case.
Delivery Time 40-50 days as usual delivery,30-40days for urgent delivery
Payment Terms L/C, T/T, Western Union
Supply Ability 1000 sets one year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Steel Load Capacity 1-1500T, Customized 250 Ton
Cart Size Customized Exported Countries Malaysia, Australia, South Africa, Mexico
Color Yellow, Red, Blue, Gray, Customized Application Industrial Field
Power Supply Cable Drum Power Operation Type Hand Pendant+Radio Control
Warranty 24 Months Port Qingdao/Tianjin/Shanghai
Running Speed 0-20m/min Motor AC Motor
High Light

cable drum power rail transfer cart

,

250 ton rail transfer cart

,

250 ton material transfer carts

Leave a Message
Product Description

Malaysia Cable Drum Power Rail Transfer Cart 250 Ton For Sale



1. About BEFANBY Product



I. Working principle:The cable drum power rail transfer carts are powered by spring cable drums which generally installed at the bottom of the carts or one side of the rail transfer cart. The one side of AC 380V cable is connected with the power source and the other side is linked to the motor. The cable is wound around cable drum.

II. Main parts: Q235B cart frame, cast steel rail wheels, AC motor, Gear Reducer, Cable drum, Cable arranger, Electrical control box,Hand-held pendant, Remote Control, Alarm Light

Cable Drum Power Rail Transfer Cart 250 Ton For Material Load 0Cable Drum Power Rail Transfer Cart 250 Ton For Material Load 1







16 Ton Cable Drum Powered Transfer Trolley On Rails For Steel Plant



III. Product Manufacturing Processing



BEFANBY promise that quality is always the first concern, and BEFANBY specially set up a quality inspection department. Every time we complete a transfer carts, we must carry out strict quality control, including the appearance of electric transfer trolley, the operation of electric transfer trolley, etc.

16 Ton Cable Drum Powered Transfer Trolley On Rails For Steel Plant





IV. Technical parameter



  Model KPJ 5T KPJ-45T KPJ-150T
  Rated Load(t) 5T 45T 150T
  Table Size(mm) 3500*2000*550 5500*2500*700 10000*3000*1200
  Wheel Base(mm) 2600 4200 7000
  Rail Gauge(mm) 1435 1435 2000
  Wheel Diameter(mm) 300 500 600
  Wheel Quantity 4 4 8
  Ground Clearance(mm) 50 50 75
  Running Speed(m/min) 20 20 20
  Motor Power 1.5 5.5 15
  Max Wheel Load(KN) 25.8 174 265.2
  Reference Weight(t) 3.5 7.8 26.2
  Recommended Rail Model P18 P43 QU100



If you are interrested in our product, pls contact us.

Thank you very much, and have a good time!



16 Ton Cable Drum Powered Transfer Trolley On Rails For Steel Plant
