Durable Factory Use Rail Operated Transfer Carts

Place of Origin Henan, China
Brand Name BEFANBY
Certification CE,SGS,ISO9001
Model Number KPD
Minimum Order Quantity 1 set/sets
Packaging Details The railway transfer car will be packed by the tarp, the parts will be shipped in the high quality wooden case.
Delivery Time 20-30 days as usual delivery
Payment Terms L/C, T/T, Western Union
Supply Ability 1000 set/sets per year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Q235 Warranty 18 Months
Load Capacity 1-70T Application Industrial Field, Steel Ladle Transport
Port Qingdao/Tianjin/Shanghai Power Supply Low Voltage Rail Power
Leave a Message
Product Description
Durable Factory Use Rail Operated Transfer Carts


1. Product Introduce



The principle of low-voltage rail power supply is to reduce high voltage (such as 380V) to a safe voltage (such as 36V) through a step-down transformer, and then transmit the electric energy to the track, and then transmit the current to the motor through the power-taking device on the flat car to drive the flat car to run. This power supply method is common in mass transportation systems and material handling equipment, and is safe and flexible. ‌

  • Working principle

‌Power supply step-down‌: First, the high voltage (such as 380V) is reduced to a safe voltage (such as 36V) through a step-down transformer to ensure safety during the power supply process.
‌Electricity transmission‌: The stepped-down electric energy is connected to the insulated track through a wire, and the power-taking device on the flat car contacts the track through a contactor or a power-taking block to obtain electric energy.
‌Motor drive‌: The obtained electric energy is converted into mechanical energy through the motor on the flat car to drive the flat car on the track.

Common types

  • There are two main types of low-voltage rail power supply:

‌Two-phase power supply‌: Suitable for flat cars with smaller tonnage, usually two tracks are laid, and DC motors are used.
‌Three-phase power supply‌: Suitable for large-tonnage flat cars, it is necessary to lay three tracks and use AC motors. Usually, the 36V electricity is increased to 380V through a step-up transformer to meet the motor needs.



Please contact us if you's like to learn more details and get the quotation.



BEFANBY have over 20 years' experience in the material handling fields.



Durable Factory Use Rail Operated Transfer Carts



Product Parts



Durable Factory Use Rail Operated Transfer Carts



2. Advantage



The advantage of rail transport car is that it is not only safe, but also not afraid of hot, does not hinder cross-transportation, not afraid of smashing,  easy to realize remote control and automation, can drive on curved roads and circular roads, and increase the number of step-down transformers properly. The limitation of the running distance of the rail ladle transport car is very convenient for the transportation plane layout of the plant.
Durable Factory Use Rail Operated Transfer Carts



Durable Factory Use Rail Operated Transfer Carts



3. Technique Parameter
KPD series is a low-voltage power supply without towing cable electric transport car; KPX series is a battery electric motorized rail transport car; KPJ series is a cable reel powered transport car; KPT series is a tow cable powered electric transport car; KPC series is a safe sliding line Powered electric transport car.

Model KPD-2t KPD-5t KPD-10t KPD-16t KPD-20t KPD-25t KPD-30t KPD-40t KPD-50t KPD-63t
Rated load 2 5 10 16 20 25 30 40 50 63
Table size Length(L) 2000 3500 3600 4000 4000 4500 4500 5000 5500 5600
Width(W) 1500 2000 2000 2000 2200 2200 2200 2500 2500 2500
Height(H) 450 450 500 500 550 600 600 650 650 750
Wheel Base 1200 2500 2600 2800 2800 3200 3200 3800 4200 4300
Rail Inner Gauage 1200 1435 1435 1435 1435 1435 1435 1435 1435 1435
Wheel Diameter 270 300 300 350 350 400 400 500 500 600
Wheel Quantity 4 4 4 4 4 4 4 4 4 4
Ground Clearance 50 50 50 50 50 50 50 50 50 75
Running Speed 0-25 0-25 0-25 0-20 0-20 0-20 0-20 0-20 0-20 0-20
Motor Power 1 1.2 1.6 2 2.2 3 3.5 4 5 6.3
Transformer Power 3 5 5 6.8 6.8 6.8 10 10 10 20
Transformer Quatity 1 1 1 1 1 1 1 1 1 1
Running Distance 80 80 80 80 80 80 80 60 50 50
Max Wheel Load 14.4 25.8 42.6 64.5 77.7 94.5 110.4 142.8 174 221.4
Reference Weight 2.8 3.6 4.2 5.5 5.9 6.5 6.8 7.6 8 10.8
Recommended Rail Model P15 P18 P18 P24 P24 P38 P38 P43 P43 P50
