Heavy Duty 100t Coil Rail Transfer Cart For Material Handling

  • Heavy Duty 100t Coil Rail Transfer Cart For Material Handling
  • Heavy Duty 100t Coil Rail Transfer Cart For Material Handling
  • Heavy Duty 100t Coil Rail Transfer Cart For Material Handling
  • Heavy Duty 100t Coil Rail Transfer Cart For Material Handling
Place of Origin Henan,China
Brand Name BEFANBY
Certification CE,SGS,ISO9001
Model Number KPD-Coil
Minimum Order Quantity 1 set/sets
Price Negotiation
Packaging Details The motorized slab trolley will be packed by the tarp, the parts will be shipped in the high quality wooden case.
Delivery Time 20-30 days as usual delivery
Payment Terms L/C,T/T,Western Union
Supply Ability 1500 set/sets, per year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Color Customized Warranty 24 Months
Load Capacity Customized Power Supply Battery Operated
Port Qingdao/Tianjin/Shanghai Application Heavy Industry,outdoor,construction
Materials Steel
Leave a Message
Product Description
Heavy Duty 100t Coil Rail Transfer Cart For Material Handling
This 100-ton coil rail transfer cart is specifically designed for transporting irregularly shaped coil materials.  Featuring a high-strength frame and heavy-duty bearings, it can safely and efficiently carry and transport heavy materials such as coils and steel rolls weighing over 100 tons, and is widely used in the steel, metallurgy, and paper industries.


Heavy Duty 100t Coil Rail Transfer Cart For Material Handling 0



Heavy Duty 100t Coil Rail Transfer Cart For Material Handling 1

Our Company

Heavy Duty 100t Coil Rail Transfer Cart For Material Handling 2
 Heavy Duty 100t Coil Rail Transfer Cart For Material Handling 3
 Heavy Duty 100t Coil Rail Transfer Cart For Material Handling 4
Products Features

Ultra-high load capacity: The vehicle body is designed with high-strength steel and a box-beam structure, ensuring stability even under heavy loads of up to several hundred tons, making it suitable for various large coil transportation tasks.

Precise directional control: Equipped with an intelligent control system, it ensures that the transfer cart can accurately connect to the production line or target location during transportation, reducing errors and losses.

Flexible track adaptability:  Adopting a multi-functional and flexible design, the track width can be adjusted according to the actual site conditions, adapting to different production environments. It supports operation on special tracks such as S-shaped and curved tracks.

Heavy Duty 100t Coil Rail Transfer Cart For Material Handling 5


Product Parameters
Model KPX-10t KPX-16t KPX-25t KPX-30t KPX-40t KPX-50t KPX-63t KPX-80t KPX-100t KPX-150t
Rated Load (ton) 10 16 25 30 40 50 63 80 100 150
Table Size Length (mm) 3600 4000 4500 4500 5000 5500 5600 6000 6500 10000
Table Size Width (mm) 2000 2000 2200 2200 2500 2500 2500 2600 2800 3000
Table Size Height (mm) 500 550 600 600 650 650 700 800 900 1200
Wheel Base (mm) 2600 2800 3200 3200 3800 4200 4300 4700 4900 7000
Rail Inner Gauge (mm) 1435 1435 1435 1435 1435 1435 1435 1800 2000 2000
Wheel Diameter (mm) 300 350 400 400 500 500 600 600 600 600
Wheel Quantity 4 4 4 4 4 4 4 4 4 8
Ground Clearance (mm) 50 50 50 50 50 50 75 75 75 75
Running Speed (m/min) 25 20 20 20 20 20 20 20 20 18
Motor Power (kW) 2 2.2 3.5 4 5 6.3 8 10 15 15
Battery Capacity (Ah) 160 180 250 250 300 330 400 400 440 600
Battery Voltage (V) 48 48 48 48 48 48 48 72 72 72
Max Wheel Load (kN) 42.6 64.5 94.5 110.4 142.8 174 221.4 278.4 343.8 265.2
Reference Weight (ton) 4.2 5.5 6.5 6.8 7.6 8 10.8 12.8 14.6 26.8
Support Customized

Heavy Duty 100t Coil Rail Transfer Cart For Material Handling 6


Production Process
Heavy Duty 100t Coil Rail Transfer Cart For Material Handling 7
Related Products
Heavy Duty 100t Coil Rail Transfer Cart For Material Handling 8
Frequently Asked Questions
How can I operate the transfer cart?
Please don't worry, dear friend. The English user manual, parts manual will be delivered with your items together.
How to ensure your product quality?
We will free provide rail installation drawing, rail foundation construction drawing, free technical guide. And if necessary, our installation engineer will go to your factory to guide the installation.
Whether you can offer customized transfer car?
Yes, of course, we are manufacturer, and we have our own engineer group. They can work out customized design according to your requirement. The most important thing is that you tell us what you need.
Whether there is professional technician assist our installation?
Yes. We have professional installation team, who have gone to many countries to assist the installation. If you need we send technician to your factory, please let us know in advance. So that we can arrange technicians.
