65Ton Workshop Railway Transfer Cart With Coil Structure

  • 65Ton Workshop Railway Transfer Cart With Coil Structure
  • 65Ton Workshop Railway Transfer Cart With Coil Structure
  • 65Ton Workshop Railway Transfer Cart With Coil Structure
  • 65Ton Workshop Railway Transfer Cart With Coil Structure
  • 65Ton Workshop Railway Transfer Cart With Coil Structure
  • 65Ton Workshop Railway Transfer Cart With Coil Structure
  • 65Ton Workshop Railway Transfer Cart With Coil Structure
Place of Origin Henan,China
Brand Name BEFANBY
Certification CE,SGS,ISO9001
Model Number KPD
Minimum Order Quantity 1 set/sets
Price Negotiation
Packaging Details Electrical parts will add shields. As required by the customer, we can add a fixed packing.
Delivery Time 20-30 days as usual delivery
Payment Terms L/C, T/T, Western Union
Supply Ability 1000 set/sets per year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Q235 Color Customized
Application Industrial Field Running Speed 0-20m/min
Operation Type Hand Pendant + Radio Control Power Supply Low Voltage Railways
Warranty 24 Months Load Capacity 1-1500T
Port Qingdao/Tianjin/Shanghai
High Light

Workshop Steerable Transfer Cart

,

Rails Steerable Transfer Cart

,

Scissor Lifting Powered Rail Cart
Leave a Message
Product Description
65Ton Workshop Railway Transfer Cart With Coil Structure



Steerable transfer car is powered by low voltage electricity from railways, the kind of rail transfer car is one of the most convenient and it ofen be widely used in the industry field an so on. Of course,compaired other transfer cars,its main features as it follows,its rails is insulated with the ground, and its wheels are isulated with the ground, so doesn't others.it is the advantage that the transfer cars have, why we disign is that its convenient (only rails needed) and its simple operation. About us, Our company have professional team and utilize more advanced technique to make it , and it has been a long year to manufacture it attentively.Simutaneously,it will be more easy and flexible.



Technique Parameter

Model KPDZ-2t KPDZ-5t KPDZ-10t KPDZ-16t KPDZ-20t KPDZ-25t KPDZ-30t KPDZ-40t KPDZ-50t KPDZ-63t
Rated load 2 5 10 16 20 25 30 40 50 63
Table size Length(L) 2000 3500 3600 4000 4000 4500 4500 5000 5500 5600
Width(W) 1500 2000 2000 2000 2200 2200 2200 2500 2500 2500
Height(H) 450 450 500 500 550 600 600 650 650 750
Wheel Base 1200 2500 2600 2800 2800 3200 3200 3800 4200 4300
Rail Inner Gauage 1200 1435 1435 1435 1435 1435 1435 1435 1435 1435
Wheel Diameter 270 300 300 350 350 400 400 500 500 600
Wheel Quantity 4 4 4 4 4 4 4 4 4 4
Ground Clearance 50 50 50 50 50 50 50 50 50 75
Running Speed 0-25 0-25 0-25 0-20 0-20 0-20 0-20 0-20 0-20 0-20
Motor Power 1 1.2 1.6 2 2.2 3 3.5 4 5 6.3
Transformer Power 3 5 5 6.8 6.8 6.8 10 10 10 20
Transformer Quatity 1 1 1 1 1 1 1 1 1 1
Running Distance 80 80 80 80 80 80 80 60 50 50
Max Wheel Load 14.4 25.8 42.6 64.5 77.7 94.5 110.4 142.8 174 221.4
Reference Weight 2.8 3.6 4.2 5.5 5.9 6.5 6.8 7.6 8 10.8
Recommended Rail Model P15 P18 P18 P24 P24 P38 P38 P43 P43 P50

65Ton Workshop Railway Transfer Cart With Coil Structure 065Ton Workshop Railway Transfer Cart With Coil Structure 1
65Ton Workshop Railway Transfer Cart With Coil Structure 2

Our Company

65Ton Workshop Railway Transfer Cart With Coil Structure 3



Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd is a collection of research, design, manufacture, installation and after-sales service of electric handling bogie ,transfer carts as one of the professional manufacturing company, which has a modernized management team and excellent staff.And our prodcuts gets CE, SASO,SGS,ISO certificate and other 8 national patent, our products have been exported to more than 40 countries and regions,such as Germany, Mexico, USA, Turkey, South Africa, Singapore etc.

Why Choose Us


65Ton Workshop Railway Transfer Cart With Coil Structure 4


Processing


65Ton Workshop Railway Transfer Cart With Coil Structure 5



Delivery & Packing


65Ton Workshop Railway Transfer Cart With Coil Structure 6



Our After Service
  •
  • 1> The load bearing safety factor of the trolley is no less than 120%.
  • 2>Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material
  • 3> 16 hours engineering service and 24 hours internet service for our customers
  • 4> During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.
  • 5> Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.
